Rated voltage: AC100V~240V 50/60Hz
Input power: 500W
Light source specification: 7 60W four in one LED Osram light sources
Rated lifespan: 50000 hours
Colors: Red, Green, Blue, White, Multiple Colors
Focusing: 4 ° -60 ° DMX linear focusing with automatic focusing function
Color temperature control: built-in CTO DMX linear dimming
Electronic strobe, 0.3-25 times/second, can choose synchronous or asynchronous random strobe
Dimming: Electronic dimming with 0-100% linear adjustment, with gamma curve dimming frequency adjustable from 1.2K to 25K, macro command dimming with linear stability and smoothness without flicker, using stable constant current drive and power supply, suitable for video recording and shooting
Rotation angle: The XY axis is driven by a high-speed silent 60 three-phase motor, coupled with a high-precision imported Hall positioning device, making the operation positioning more accurate. When there is a misoperation, it can automatically return to its original position, and the horizontal and vertical speeds can be adjusted; XY axis rotation function and reverse function,
Horizontal direction 540 ° (16 bit precision scan), vertical direction 270 ° (16 bit precision scan)
Control mode: 30 (simplified) 30/42/58 (standard) 3 channel control modes, standard DMX512 protocol, RDM protocol
Control interface: DMX512 interface (3-core/optional 5-core), power cord handle socket
Sleep function: Advanced technology is used to achieve remote sleep function. When the light fixture disconnects the signal, it automatically enters sleep mode, making the light fixture more stable and safe
Display function: 1.77-inch LCD screen, bilingual menu in Chinese and English, sensor fault display, temperature display
Cooling system: High conductivity lightweight aluminum radiator is used, and the intelligent monitoring technology of the fan automatically adjusts the fan speed according to the temperature of the lamp. The built-in overheat protection intelligent system/intelligent temperature and noise balance module
Protection level: IP20, optional rain cover protection level up to IP44
Lamp packaging: waterproof and shockproof aviation box or cardboard box
Net weight: 16.5KG
Gross weight: 19KG
Product size: 40.5 * 23.4 * 44CM
Packaging size: 49 * 47 * 39CM (one pack, one)
Effect mode: (Vortex, Kaleidoscope)
